Vital Track -VII 15″
Product Description
- 15 inch Multicolor TFT
- Inbuilt Battery Operation
- Adult/Pediatric/Neonate Application
- 11 Channel configurable waveform display
- 96hr trends for SPO/HR/Resp/Temp/ETCO/IBP
- Trend of 100 NIBP Readings
- Wired/Wireless Connectivity
- Printing to external
- 100 Event Storage
- Upgradeable to IBP & ETCO2
- Drug calculation
Specifications
| TEMPRATURE (2 Channel) | |
| Sensor | Compatible to YSI 400 series |
| Resolution | 0.1 Degree C |
| Measurement Range | 10 to 45 Degree |
| Unit | C/F |
| Accuracy | 0.1 Degree C |
| IBP | |
| Measurement Method | Pressure Transducer Method |
| Display | Systolic, Mean, Diastolic with waveform |
| Channels | 2 (IBP1 & IBP2) |
| Measurement Range | -40 to 300mmHg |
| Display Accuracy | ± 3 mmHg |
| Pulse Rate Measurement Range | 20 to 250 BPM |
| IBP Scaling | 37, 75, 150 and 300 |
| ETC02 | |
| Method | Non-dispersive infrared Spectroscopy |
| Transducer Type | Sidestream CO2 Sensor |
| CO2 Measurement Range | 0 - 150mm Hg |
| CO2 Resolution | 0.1 mm Hg (0-69 mm Hg) 0.25mmHg (70-150 mm Hg) |
| Co2 Accuracy | >0-40 mm Hg (±2 mm Hg) 41-70 mm Hg (±5%ofreading) 71-100 mm Hg (±8%of reading) 101-150 mm Hg (± 1CP/o ofreading) |
| DISPLAY | |
| Type | Color TFT Display |
| Size | 15" Diagonally |
| Resolution | 1024 x 768 dots |
| ELECTRICAL | |
| Power input | 90-270 V AC, 50-60 Hz |
| Inbuilt Battery Type | Li-Ion |
| Battery Rating | 11.1V, 4000mAh |
| Charging Time | 8-10 Hours |
| Operating Time | > 2 Hours |
| Power Consumption | < 35W |
| GENERAL | |
| Dimensions | 360(L)x140(W)x340(H)mm |
| Weight | 3.5 Kgs Max |
| Operating Temprature | upto 40 Degree C |
| Storage Room Temprature | upto 55 Degree C |
| Relative Humidity | upto 90% Non-Condensing |
