Iris 70 10.4”

Product Description

10.4 inch Multicolor TFT
Adult/Pediatric/Neonate Application
5 Channel configurable waveform display
Inbuilt Battery Operation
96hr trends for SPO2/HR/Resp/Temp/ETCO2/IBP
Trend of 100 NIBP readings
100 Event Storage
Wired/Wireless Connectivity

Specifications

Example
ECG
Channel 11 Channel
Electrode 3/5 lead
Display Waveforms with HR
Lead Lead I, II, III, aVr, aVI, aVf, V
Gain Selection 0.5, 1, 1.5 or 2
Sweep Speeds 12.5,25 or 50 mm / sec
Heart Rate Range 20 - 250 bpm
Heart Rate Accuracy ± 2 BPM
Frequency Response 0.05 to 40 Hz
CMRR > 100 dB
Input impedance > 100 M ohms
DISPLAY
Type Color TFT Display
Size 15" Diagonally
Resolution 1024 x 768
ELECTRICAL
Power input 90-270 V AC, 50-60 Hz
Inbuilt Battery Type Li-Ion
Battery Rating 11.1V, 4000mAh
Charging Time 8-10 Hours
Operating Time >2 Hours
Power Consumption < 35 W
GENERAL
Dimensions 365(L) x 182(W) x 320(H) mm
Weight 3.5 Kgs Max

..

Example
SpO₂
Technique Transmission Method
Display Plethysmograph, pulse amplitude, indicator,
Pulse rate and % of oxygen saturation
Sweep Speeds 12.5, 25 or 50 mm/sec
SpO2 0-100%
SpO2 Accuracy ± 2 for 70 - 100% and
± 3 for 40 - 70%
Sweep Speeds 12.5,25 or 50 mm / sec
NIBP
Method Oscillometric Measurement
Display Systolic, Mean, Diastolic
Operation Modes Auto, Manual, Stat
Interval 2 - 120 Minutes
Range 0 - 300 mmHg
Pressure Accuracy ± 3 mmHg
Measurement Time 30 to 150 seconds
RESPIRATION
Method Impendance Pneumography
Display Respiration wave form with RR
Sweep Speed 6.25 / 12.5 / 25 / 50 mm / sec
Range 4 to 150 BPM
Apnea Alarm 10 - 90 Secs
TEMPRATURE
Sensor Compatible to YSI 400 series
Resolution 0.2 degree C
Measurement Range 12 to 43 Degree
Unit C / F

Warranty: 12 Months from the date of manufacturing
